It adopts high-efficiency class D amplifying circuit and built-in high-efficiency switching power supply, which makes the whole machine efficiency up to 85%;The internal heat dissipation layout of the product makes the product maintain the working temperature below 60 degrees even in the extremely harsh working environment, which greatly prolongs the service life of the equipment.
Features
1. Providing 2 channel of 100V output terminal wiring speaker.
2. The fault output function can remotely monitor the working state of amplifier.
3. The product has short circuit, overload and overheat protection.
4. 1.5U standard rack design.
5. With 2-channel European terminal balanced input, 2-channel European terminal output.
Technical Specification
| Model |
AW-AP2500 |
| Power Supply |
220-240VAC ,50HZ/60HZ |
| Rated Power Output |
2*500W |
| Input Sensitivity (impedance) |
±500mV/20KΩ,Balance input |
| Frequency Response |
80Hz~16KHz (+1, -3dB) |
| Signal-to-noise Ratio |
≥95dB |
